Description
The Jimmie is a portable and lightweight power chair designed for the consumer on the go. The unit has a quick-disconnect system for effortless disassembly, advanced electronics, and high-efficiency in-line motors. The Jimmie disassembles effortlessly into three pieces, with the heaviest weighing just 35.8 lb. It also has all the features of larger power chairs including height & width adjustable armrests, adjustable footplate, and adjustable seat height.
Features
Some of the key features for Shoprider Jimmie Power Chair include:
- High-efficiency in-line motors
- Wireless Take-A-Part technology
- Rear-wheel drive
- Extra light, only 106 lbs. (incl. batteries)
- Easily assembles with connectorless technology
- Disassembles into three easy to manage parts
- Adjustable seat height
- Padded, full-feature armrests
- Removable fold up footrest
- 0.45 hp x2 Motor Power Output Horsepower
- 2 amp Charger-Off Board
- Heaviest Part: 35.4 lbs
Shoprider Jimmie has an ultra-tight 26″ turning radius Plus, this model weighs just 106 lbs. (incl. batteries).
Specifications
View specs below for Shoprider Jimmie (Model Number: UL8WPBS)
| OVERALL DIMENSIONS | |
| Base Length | 35″ |
| Base Width | 21.5″ |
| Height (UL8WPBS) | 36.5″ |
| Ground Clearance | 2″ |
| WEIGHTS | |
| User Weight Capacity | 250 Lbs |
| Front Chassis w. batteries | 35.4 Lbs |
| Rear Chassis w/ drive train | 29.9 Lbs |
| Total Weight | 106.1 Lbs |
| Battery pack weight | 19.3 Lbs |
| Captain seat w/arms/controller assy | 37.3 Lbs |
| Seat Dimensions | 18″w x 17.5″d x 19″h seat pad 4″ |
| TIRES | |
| Front Tire | 6″ |
| Rear Tire | 9″ |
| BATTERIES | |
| Battery capacity | 2 x 12v-12amp |
| CHARGER | |
| Charger-Off Board | 2 amp |
| MOTOR POWER OUTPUT | |
| Horsepower | 0.45 x2 |
| DRIVING SPECS | |
| Turning Radius | 15.5″ |
| Range | up to 10 miles |
| Maximum Speed | 3.75 mph |
| Maximum Climbing Angle | 10% / 6° |
Warranty
3-Year Warranty on Frame
1-Year on Electronics, Motor, Transaxle, Brakes
