Description
Acrobat HD ultra’s new Full HD 3-in-1 camera provides the best image quality available today! Enjoy brighter sharper colors and bold contrast with this feature rich electronic magnifier. A wider field of view allows you to see even more of what you want.
It’s our most flexible solution for reading,writing or viewing magnified images atany distance. Use it up close like a mirrorfor applying make-up or other personalgrooming.
By simply rotating the camera you canmagnify images in the distance. Use itto view presentations, paperwork, evenwork on crafts and hobbies. Acrobat HDultra is ideal for work, school or home.
ACROBAT HD ULTRA LCD is a completesystem featuring a 3-in-1 Full HDcamera with a 20”, 22”, 24”, or 27” highresolution HD LCD producing maximumpicture detail for clear, vivid color display.
The adjustable arm, tilting screen, androtating capability allows the camera to bepositioned at any angle for optimal viewing.
Features:
- Full HD 1080p auto focus 3-in-1 camera for seeing yourself up close, reading and distance viewing
- Light on/off feature
- Three position monitor height adjustment provides maximum flexibility
- 28 available viewing modes to optimize contrast and brightness
- True mirror image in self-viewing mode
- Remote control unit features instant on/off (standby)
- Memory setting for each HD camera position
- Compact size minimizes space needed on table or desk
- 28 available viewing modes to optimizecontrast and brightness
- Line markers and object locator
- Remote control unit features instant on/off(standby)
- Computer compatible (additionalhardware required)
- 20”, 22”, 24” or 27” high resolution HD LCD monitors provide 1.4x to 71x adjustable magnification (varies with LCD size)
- Set up is easy, just plug in and begin
- 2 year warranty
- Designed and Assembled in the USA
Specifications
Product Dimensions:
20” LCD: 21”H x 19”W x 8”D (53cm x 48.25cm x 20cm)
22” LCD: 21”H x 20”W x 8”D (53cm x 51cm x 20cm)
24” LCD: 21”H x 22”W x 8”D (53cm x 56cm x 20cm)
27” LCD: 21”H x 25”W x 8”D (53cm x 63.5cm x 20cm)
Product Weight:
20” LCD: 18.4 lbs / 8.35 kg
22” LCD: 18.6 lbs / 8.5 kg
24” LCD: 19.6 lbs /8.9 kg
27” LCD: 21 lbs / 9.5 kg
Display:
Type: TFT Active Matrix LCD Average lifetime: 25,000 hours
Monitor (common to *20”, *22″,*24 & *27″ models):
Resolution: 1600 x 900 (20″ model)
Resolution: 1920 x 1080 (22”, 24” & 27″ models)
Response Rate: 5 milliseconds (20”, 22″ & 24″ monitors)
Response Rate: 3 milliseconds (27” monitor)
* all monitor specifications subject to change without prior notice
Magnification range:
20” LCD: 1.4X (minimum) – to 52.5X (maximum)
22” LCD: 1.5X (minimum) – to 57.8X (maximum)
24” LCD: 1.6X (minimum) – to 63X (maximum)
27” LCD: 1.8X (minimum) – to 70.9X (maximum)
20”, 22” 24” Field of View (Near Mode): 10.8 inches (min); .24 (max)
27” Field of View (Near Mode): 11.6 inches (min); .24 (max)
20”, 22” & 24” Working Distance (Near Mode): 17 inches
27” Working Distance (Near Mode): 18.4 inches
Video output Resolution on LCD:
SMPTE 292M – HD 1080p 60/50Hz
Viewing Modes:
Color, Black & White, High Contrast, Positive/Negative, Digital Color Select (5 modes)
Power Supply:
Input voltage/current: 120-240 VAC / 0.3-0.5A (nominal)
Frequency: 60/50 Hz
Power usage: 27W (nominal)
Equipment Classification: (IEC 601-1)
Type of Protection: Class 1
Degree of Protection: Type B
Mode of Operation: Continuous
Operating temperature range: 10-40°C / 50-104°F
Storage/transport temperature range: 0-60°C / 32-140°F
Warranty: 2 years
